BMMBaroda Machinery Manufacturers
Products & Services

Complete foundry plants and equipment — designed, built, commissioned.

Every machine BMM builds for the foundry process, from sand preparation to casting finishing, for grey iron, cast steel and non-ferrous foundries, supplied as a turnkey plant or as individual equipment.

Enquire
How we work

From the first layout to a running plant

Five decades of turnkey foundry engineering, from layout design to commissioning and plant expansion. For grey iron, cast steel and non-ferrous foundries.

Design

Mechanized turnkey foundry projects, with complex engineering designs for complete and sectional layouts and tailor-made machinery.

Manufacture

Foundry equipment built to your layout and production target.

Install & Commission

Installation, erection and commissioning, including site fabrication.

Expand & Modernize

Repairs, maintenance, retrofits, rebuilds and plant modification for existing foundries.

On-site work we handle

  • Decommissioning & removal of existing machinery
  • Datum survey & alignment checks
  • Floor marking & positioning checks
  • Mechanical installation of ancillary equipment
  • Alignment & levelling
  • Electrical rewiring with PLC control units, cabinets & total plant integration
  • Testing & pre-commissioning
The foundry process

Where BMM equipment fits

Select a step to jump to the machines for it. BMM builds almost all the equipment a foundry needs.

Range 01

Sand Preparation & Handling

Sand plants and the machines inside them: mixing, cooling, drying, screening, conveying and control.

BMM builds sand plants from compact 3 to 20 TPH mini plants to tower-type and high-pressure moulding line plants of 20 to 150 TPH, and can design for higher capacity. They run on sequential or PLC-based electrical control, and the machines inside them are made by BMM: intensive mixers and mixer-mullers, rotary drum driers and coolers, aerators, sieves, magnetic separators, conveyors and elevators.

Green sandNo-bake
120 TPH Sand Plant — 120 TPH Sand-Plant -1
Project

Turnkey 120 TPH sand preparation plant with PLC automation and a sequential dual type control unit.

120 TPH, PLC-controlled

Green sand2 photos
Sand Plant for High-Pressure Moulding Line — SAND PLANT for High Pressure Moulding Line

Fully automatic sand plant for a high-pressure flaskless moulding line, 20 to 150 TPH.

20–150 TPH

Green sand
Tower Type Sand Plant — Over View of-Sand Plant

Sand plant that needs less floor space and more height, 20 to 150 TPH.

20–150 TPH

Green sand
Mini Sand Plant — Mini Sand Plant

Comprehensive, compact sand plant, 3 to 20 TPH.

3–20 TPH

Green sand
Intensive Sand Mixer — Intensive Mixer Inside View

Mixer that gives a homogeneous mix of sand, bentonite, coal dust, water and fine dust.

150–1500 kg batch

Green sand3 photos
Mixer-Muller — Sand Mixer Muller ( Mini Size)

Mixer-muller for optimum green sand moulding strength and compactibility, 50 to 1500 kg per batch.

50–1500 kg batch

Green sand3 photos
Sand Aerator (Line Aerator) — Sand-Aerator

Overbelt-mounted line aerator that turns sand lumps into free grains without disturbing the binder coating.

Twin, single drum or combi

Green sand
Rotary Drum Sand Cooler — Rotary Sand Cooler

Almost zero-maintenance rotary drum cooler for hot return sand after shakeout.

Green sand2 photos

Fluidized bed sand cooler, developed by BMM and unique in its design.

Green sand
Rotary Drum Sand Drier — Sand Drier Complete View

Rotary drum sand drier, single and double pass, that saves fuel and energy.

Single & double pass; oil, gas or hot-air

Green sandNo-bake2 photos
Polygonal Sieve & Vibrating Screen — Polygonal Sieve Complete Assembly

Sieves and screens that condition return green sand.

Green sand4 photos
Skip Charger — Skip Charger-Top View

Side-dump hoisting bucket that conveys sand to a height and batches it into the mixer.

Green sand2 photos
Single & Double Pivot Turning Belt Feeder — Double-Pivot-Belt-Conveyor

Turning belt feeder that carries green sand from the mixer/muller junction into moulds above 5000 kg.

Moulds above 5,000 kg

Green sand
Belt Conveyors, Bucket Elevators & Screw Conveyors — Feeder Belt Conveyor

Rigid, robust belt conveyors, bucket elevators and screw conveyors conforming to IS, ASTM and CEMA standards.

IS / ASTM / CEMA standards

Green sandNo-bake8 photos
Inline / Vibratory Feeder — Inline Feeder photo

Vibratory feeder that takes the surge load of sand and regulates its output feed.

Green sandNo-bake

High-intensity electromagnetic or permanent magnetic separators and pulleys, supplied with a belt conveyor.

Electromagnetic or permanent

Green sandNo-bake
BMM-developed

Triple-action powered belt cleaner, developed by BMM and unique in its design.

Green sandNo-bake
Sequential & PLC Electrical Control Units — Control Unit for 120 TPH Sand Plant

Sequential and PLC-based electrical control units for plant and equipment operation.

Green sandNo-bake6 photos
Range 02

Core Shop Automation

Core sand mixing, core handling and core-making automation.

BMM's high-speed core sand mixers give a very fast sand mix at very low power consumption, with core oil, organic or inorganic binders in two-part or three-part form. Mixers with weighing batch hoppers and binder dosing, core sand preparation and distribution systems, and core handling conveyors and carousels are run from semi-automatic or fully automatic PLC control cabinets.

Green sandNo-bakeDie, centrifugal & investment casting
High Speed Core Sand Mixer — Core Sand Mixer

Fast core sand mixer with very low power consumption and self-cleaning S-shaped blades.

2- and 3-part binders

All foundry types
Core Sand Mixer with Weigh-Batch Hopper & Binder Dosing — New Intensive Mixer-Discharge View

Core sand mixer integrated with a weighing batch hopper and binder dosing system.

PLC-controlled

All foundry types
Core Handling Conveyors — corehandlingconveyors

Slide bed, link pallet, indexing pallet and overhead monorail conveyors for handling cores.

Slide bed, link pallet, indexing pallet, overhead monorail

All foundry types2 photos

Automation for core dipping, drying and stacking.

All foundry types
Range 03

Mould Handling — Green Sand Lines

Cars, conveyors and manipulators that move moulds through a green sand moulding line.

Pallet and mould cars, pneumatic and hydraulic pushers, turn tables, transfer trolleys, mould manipulators and roller conveyors for semi-automatic and automatic green sand moulding lines, with flask or flaskless moulds. They suit small to large moulds, and powerised transfer trolleys move very large moulds of about 5 tonnes and above.

Green sand
Pallet / Mould Cars — Pallet-Mould Cars for Automatic Line

Robust, economical pallet and mould cars, power-operated or manual push-pull.

Green sand2 photos
Turn Table — Turn Tables

Turn table that diverts moulds in another direction for further processing.

Green sand
Transfer Trolley — Transfer Trolley Junction of Moulding Line

Powerised or non-powerised trolleys that index moulds from one place to another.

Green sand
Pneumatic / Hydraulic Pusher — Pneumatic Pusher Assly.

Pneumatic or hydraulic pusher, chosen by load, size and number of pallets.

Green sand2 photos
Mould Manipulator (Transfer & Closing Machine) — Mould Box Manipulator

Custom-built mould transfer and closing machine (mould manipulator), for any type and size of mould.

Green sand2 photos
Roller Conveyors — Combined Roller Conveyor

Powered and non-powered roller conveyors that move boxes from the moulding station to the closing and pouring area.

Powered or non-powered; plain, guide-collar, stub

Green sand4 photos

Automatic indexing on pallets, for mould handling and transfer.

Green sand

Metallic CI plate conveyor, for mould handling and transfer.

Green sand

Cooling belt conveyor, for mould handling and transfer.

Green sand
Range 04

No-Bake Moulding & Sand Reclamation

Moulding lines and sand reclamation for the no-bake process.

BMM has designed, manufactured and commissioned a fully automatic fast loop flaskless moulding line with a flaskless mould pouring line, for a wide range of mould sizes. No-bake moulding carousels are sized to the pattern and the curing time of the mould, and the plant also includes shakeout and knockout machines, return sand conveyors and sand reclamation units of 3 TPH to 20 TPH and more.

No-bake
Fully Automatic Fast Loop Moulding & Pouring Line — automatic fast loop moulding pouring

Fully automatic Fast Loop flaskless moulding and pouring line, for a big range of mould sizes.

No-bake9 photos
Fast Loop Moulding Line with Roller Conveyors & Turn Table — fast loop roller conveyor

Fast Loop moulding line for a variety of no-bake pattern sizes.

No-bake
Sand Reclamation Unit — Mechanical Shakeout-1

Mechanical shakeout/knockout with attrition unit that converts sand and mould lumps into clean grains, 3 to 20+ TPH.

3–20+ TPH

No-bake2 photos
Range 05

Pouring Systems

Equipment that moves molten metal from furnace to mould safely.

HITECH POUR, made only in India by BMM, moves liquid metal without a crane on six axes of movement and is run by radio remote control from a safe distance. EZEE POUR is an intelligent pouring system with an accurate pouring rate and high metal recovery, and needs no pit or foundation. Vertical Track Technology (VTT) pours with high accuracy and minimum spillage, and overhead monorail and bi-rail systems are the best alternative to pouring by EOT crane. One-man pouring ladle handlers lift and lower the ladle with zero jerks.

Green sandNo-bakeDie, centrifugal & investment casting
HI-TECH POUR — Complete-View-of-Hi-Tech-Pour
BMM-developed

Floor-travelling, six-axis liquid metal transfer machine with radio remote control. Made only in India by BMM.

Green sandNo-bake
EZEE POUR — Ezee Pour
BMM-developed

Pouring equipment with accurate pouring rate and the highest possible metal recovery; needs no pit or foundation.

All foundry types
Vertical Track Technology (VTT) — VTTTop View
BMM-developed

Vertical-track pouring system with high accuracy and minimum spillage.

Green sand2 photos
Overhead Monorail / Bi-Rail Powered Pouring System — Pouring by Monorail OR BiRail

Powered pouring on an overhead monorail or bi-rail, the best alternative to pouring by EOT crane.

Green sandNo-bake3 photos
One-Man & Powered Ladle Handlers — Powerised Ladle Handler

Powerised ladle handler that lifts and lowers the ladle smoothly, with zero jerks.

Green sandNo-bake4 photos
Hot Metal Transfer Trolley (Powered Ladle Car) — Powered Ladle Car

Powerised and non-powerised trolleys that transfer liquid metal safely, jerk-free and by radio remote control.

All foundry types
Range 06

Ladles & Ladle Pre-heaters

Treatment, pouring and transfer ladles, and the pre-heaters that go with them.

BMM makes light, medium and heavy duty ladles, standard or tailor made: lip pouring, tea spout, bottom pouring, drum, square, double shell and lidded ladles, for right-hand or left-hand pouring and with gearbox, lever or non-geared tilting. BMM's SG iron treatment ladles with tundish are used in foundries in India and abroad, designed to increase magnesium recovery, reduce temperature losses and cut slag and dross. Ladle pre-heaters with liquid fuel or gas burners save fuel and time.

Green sandNo-bakeDie, centrifugal & investment casting
SG Iron Treatment Ladle with Tundish — final SGI-cum-Pouring-Ladle-with-Tundish

Treatment ladles that increase magnesium recovery, with tundish, lid or open-top options.

Green sandNo-bake5 photos
Square Type Ladle (Treatment / Pouring) — Treatment cum Pouring Ladle

Square ladle for SG iron treatment and pouring, treatment only, or pouring only.

Green sandNo-bake2 photos
Lip Pouring Ladle — LIP POURING LADLELarge Capacity

Light-, medium- and heavy-duty lip pouring ladles, standard or tailor-made.

All foundry types4 photos
Tea Spout Ladle — Special TSpout Pouring Ladle with Gear for Tilting small

Tea spout ladles in many variants and capacities, right- or left-hand pouring.

All foundry types3 photos
Bottom Pouring Ladle — Bottom Pouring Arrangement

Bottom pouring ladle for steel casting foundries, with slag-free pouring from the base.

Mainly used by steel casting foundries

No-bake2 photos
Cylindrical (Drum) Ladle — Drum Type Ladles

Cylindrical (drum shape) ladles with various spout arrangements, geared or non-geared, with or without lid.

All foundry types3 photos
One-Man Pouring Ladle — Lever type tilting Ladle with top LID

Small-capacity ladles with gearbox and hand wheel or lever tilting; motorised tilting available.

All foundry types4 photos
Ladles with Top Lid — Ladles with Lifting and Swivelling type Top LID

Ladles with a swivelling or lifting-swivelling lid that prevents heat loss in transit and pouring.

All foundry types3 photos
Double Shell Pouring & Transfer Ladle — TSpout type Double Shell Ladles

Double-shell ladles with almost zero heat loss from the sides; with or without tilting gear.

All foundry types2 photos
Ladle Pre-heaters — PreHeater Swivelling Type

Compact, safe ladle pre-heaters that save fuel and time; liquid or gas fuel burners.

Swivelling, auto gas-fired, portable vertical or horizontal

All foundry types4 photos
Range 07

Shakeout, Fettling & Casting Handling

Shakeouts, feeders and fettling lines that take castings from mould to dispatch.

BMM's fettling carousel runs five to six operations in parallel, for grinding, cleaning, reburring and finishing, with castings held on multi-axes fixtures. Metallic bed and apron conveyors handle, fettle and stack castings automatically and carry them into the shot blasting system. BMM has designed and made shakeouts and knockout machines since 1976.

Green sandNo-bakeDie, centrifugal & investment casting
Shakeout — 60 Ton Capacity Shakeout

Shakeouts designed and made by BMM since 1976, with adjustable rate and travel of sand and casting.

Self-discharge; single, twin, 4-station; up to 60 T

Green sandNo-bake5 photos
Knockout-cum-Feeder — Knockout cum FeederLarge capacity

Knockout-cum-feeder for medium and large sizes, in eccentric shaft or vibratory motor design.

Eccentric shaft or vibratory motor

Green sandNo-bake4 photos
Metallic Bed / Apron Conveyor

Metallic bed/apron conveyor with flexible metallic top, pulling chain and drive unit.

All foundry types4 photos

Fully automatic casting handling, fettling and stacking on hangers, with conveying into shot blasting.

All foundry types
Sectors we serve
  • Automobile
  • Power & Infrastructure
  • Domestic Appliances
  • Machinery & Engineering
  • Agriculture

Don't see what you need? We build tailor-made systems too.
